PRODUCT&SOLUTION

Ultrasonic Camera

✔ (GIS : Geographic Information System)

GIS, cloud-based AI analysis function added to

From electrical discharges and Gas leaks to various noise sources!


Now meet BATCAM 2S with improved performance such as sampling rate, display, UI and more.

The newly introduced BATCAM 2S is equipped with GIS and cloud-based AI analysis capabilities to increase user work efficiency. The measurement sensitivity is increased by detecting gas leaks using 112 microphones, measure the following signals in the discharge, abnormal noise, and ultrasonic bands from 2 kHz to 100 kHz BSR (Buzz, Squak, Rattle) noise it also performs well in measuring high frequency noise.

✔ (GIS : Geographic Information System)

GIS, cloud-based AI analysis function added to

 From electrical discharges

and Gas leaks to various noise sources!


Now meet BATCAM 2S with improved performance such as sampling rate, display, UI and more.

The newly introduced BATCAM 2S is equipped with GIS and cloud-based AI analysis capabilities to increase user work efficiency. The measurement sensitivity is increased by detecting gas leaks using 112 microphones, measure the following signals in the discharge, abnormal noise, and ultrasonic bands from 2 kHz to 100 kHz BSR (Buzz, Squak, Rattle) noise it also performs well in measuring high frequency noise.


Electrical Discharge and Abnormal Noise
Electrical Discharge and Abnormal Noise
Gas and air leakage
Gas and air leakage
Noise Evaluation in Industrial Site
Noise Evaluation in Industrial Site

Product Features

Small and lightweight, making it easy to carry

  GPS location can be saved (APP connection)

  Cloud-based AI analysis available

Hardware

Hardware

  • 112 Digital MEMS Microphones
  • USB-C type data transmission and charging
  • Measurement and analysis up to 100 kHz
  • Audio and HDMI outputs
  • 5” High Luminance Touch Screen
  • Available Up to 4 Hours
  • IR range sensor
  • LCD Brightness Automatically

Software

Software

  • Visualize real-time sound sources and Display sound pressure
  • Multiple/single/Full view source Measurement mode selectable
  • Real-time air/gas estimated leakage and Loss amount
  • Real-time PRPD Analysis and Partial Discharge Measurement
  • Save images and videos (JPG/MP4/WAV)
  • Digital Zoom
  • Microphones self-test
  • Supports BATCAM Zone(Web/App) (Available in October )

Principle of Ultrasound Measurement

BATCAM

Other Processes

BATCAM ZONE

When uploading measurement data with a cloud-based WEB/APP service, it provides data history management and reports such as gas leakage and loss analysis, partial discharge type AI analysis, and GPS measurement location information.


More view

Repor tGenerator

After clicking the Report Generator menu, uploading the measured photo file by selecting the appropriate report among the gas leakage, partial discharge reports, and entering the test information, the report is generated.



More view

Application Example

Partial Discharge

Partial Discharge

Partial Discharge

Gas leakage

Gas leakage

Gas leakage

Abnormal Noise

Abnormal Noise

When a gas leak occurs, it results in ultrasonic wave element, higher than the audible frequency. Ultrasonic wave element is also made when electrical arc occurs. Therefore, in noisy environment, ultrasonic wave element can be measured to determine whether or not gas leak and electrical arc have occurred and where they have occurred. BATCAM 2S has detected a leak at a distance of 0.5m at 51cc/min (0.85cc/sec) with 1.6bar pressure pressurized.

Application Example


Specifications
Sensor(Microphone)112Ch Digital MEMS
Effective Frequency Range
2 kHz ~ 100kHz
Acoustic Measurement
Detection threshold

2 kHz : 2.34 dB SPL

20 kHz : 2.22 dB SPL

40 kHz : 1.90 dB SPL

55 kHz : 1.22 dB SPL

70 kHz : 1.84 dB SPL

100 kHz : 20.10 dB SPL

Minimum leak rate1 m, 0.02 bar, 38 cc/min
Test Distance
0.5 ~ 200m
Camera pixel / FOV
8MP / Horizontal 63º, Vertical 40º
Image Resolution
1024 x 600
Frame Rate25 FPS
Digital Zoom x3 ZOOM
Auxiliary lights LED x 2
Display Resolution5" Color LCD (800 x 480)
Brightness1000nit (Automatically and manually)
Touch ScreenCapacitive Touchscreen
Data FormatJPG, MP4, WAV
Storage / Video Length21GB (Save 8,400 Pictures, Video 20hours) / 30min


Specifications
Data transfer
USB-C, Bluetooth 5.0 Support

Operating time

(charging time)

Up to 5 hours (4 hours)
Built-in Battery

Rechargeable Battery - Li-ion

(48.24 Wh) Samsung SDI INR18650-35E

Operating temperature-20 ~ 50 ℃
Product Size (Weight)237 mm x 146 mm x 56 mm (1.1kg)
Supported Language

Chinese (Traditional, Simplified),Croatian,

Dutch, English, French, German, Japanese,

Korean, Portuguese, Russian, Spanish,

Thai, Turkish

Save GPS InformationConnects to mobile via Bluetooth
APPiOS, Android

Warranty extension program

Warranty 2 years

Additional 3 years + 1,950 USD


Model-specific features

BATCAM 2.0   More View

The small, lightweight BATCAM 2.0 measures the signals in the ultrasonic band for gas leakage and It was developed for the purpose of detecting electric arcs. Using 112 microphones It has increased measurement sensitivity and has been developed to measure signals in ultrasonic bands up to 48 kHz.


BATCAM FX   More View

It is a fixed ultrasonic acoustic camera for outdoor installation. It is an IP65 certified product that can be installed in cold and rainy outdoor environments, and real-time monitoring is possible.



Certifications
